| System Type |
Volumetric Liquid & Paste Filling System |
| Filling Type |
Pneumatic or Servo-driven Piston Filler (based on product and accuracy needs) |
| Product Suitability |
Honey, Shampoo, Sauce, Gel, Oil, Cream, Ketchup, Liquid Detergent, etc. |
| Filling Range |
10ml to 1000ml (Customizable as per requirement) |
| Accuracy |
±1% (Depending on viscosity and product flow) |
| Filling Nozzles |
Single or Multiple Nozzles (1–4 heads) |
| Nozzle Type |
Drip-free nozzles, shut-off nozzles, or diving nozzles for foamy liquids |
| Control System |
PLC with Touch Screen HMI |
| Material Contact Parts |
Stainless Steel 304/316 (Food & Pharma Grade) |
| Power Supply |
230V / 50Hz, Single Phase |
| Air Consumption |
Approx. 5–6 CFM @ 6 Bar (For pneumatic operation) |
| Application |
Suitable for pouch filling, bottles, jars, tubes, and containers |
