| Lane Configuration | 4 to 10 lanes |
|---|---|
| Sachet Size (W × L) | 10–50 mm × 50–200 mm (adjustable per lane) |
| Film Roll Width | Up to 500 mm (depending on number of lanes) |
| Filling Volume | 1 ml – 100 ml (based on product & sachet size) |
| Filling Accuracy | ±1–2% (depending on product type) |
| Production Speed | Up to 40 per Min. Per lane |
| Power Supply | 220V/380V, 50Hz/60Hz, 3 Phase |
| Compressed Air Requirement | 6 bars, 300–600 L/min |
| Construction Material | SS304 / SS316 (contact parts) |
| Filling System Offer on Machine |
Linear Weigher Multi-Head Combination Weigher Auger Filler Volumetric Cup Filler |
| Optional Accessories |
Types Of Batch Coder Gas Flushing Bucket Elevators Screw Feeder Dust Collector |
| Application |
Granules Like Sugar, Tea, Coffee, Seeds, Namkeen & many more Powder like Spices, Milk Powder, Coffee Powder, Floors & Many more |
Features
- Compact and Rugged Structure
- Easy and Quick Pouch Change Over
- Unwind with an Air Shaft
- Film End Detection
- PLC-Controlled Functionality
- Digital Temperature Controller
- Integration with various types of feeding systems and batch coders
